HVAC
6
BLOWER LPM UNIT
2. SPECIFICATION:- EVAPORATOR CORE
Please see the below sizes for Evaporator & heater core
1) Evaporator :Total size : 262 X 235 X 48.5mm
Core size : 262 X 195 X 45 mm
2) Heater :Total size : 219.6 X 181.35 X 40 mm
Core size : 184.6 X 181.35 X 34 mm
3. SPECIFICATION:- EXPANTION VALVE
PERIPHERAL STRUCTURE OF EXPANSION VALVE MUST PROTECT FROM INFLUENCE OF AMBIENT TEMP.
