32 / 745
KRYOTEC ENGINE
24
2.CRANKCASE
No. Part Number Description
Qty. Notes
1
55274879 HEAD GASKET
1
GASKET BET LOWER CYL HEAD
& BEDPLATE (Thickness 0.95mm)
1
55274880 HEAD GASKET
1
(Thickness 1.05mm )
1
55274881 HEAD GASKET
1
(Thickness 1.15mm)
2
55265045 DOWEL
2
GUIDE PIN
3
55265046 DOWEL
4
GUIDE PIN
4
55265047/
55275655
DOWEL
2
GEAR BOX CENTRAL CAP FOR
CYL BLOCK
5
14328501 PLUG (Ø16)
2
BLOCK CUP PLUG DIAM.16
5
14328701 PLUG (Ø20)
1
5
55189943 PLUG (Ø25)
1
5
14329101 PLUG (Ø30)
5
6
55218941
SCREW (Special with flange M
12x98)
10
7
55274701 PROTECTION
1
UPPER DUST COVER
