ELECTRICAL
61
REMOVAL
1. Carefully pull out air vent Cover
2. Loosen and remove the four mounting screws
of air vent
3. Disconnect the electrical connection.
4. Remove the three mounting screws and take
out the switch.
REFITMENT
Follow the removal procedure in reverse.
16 MIRROR SWITCH
For High Version
For Low Version
Mirror fold/Unfold (If applicable)-
Knob need to be in center. It should not be at left
& right mirror selection.
Pull Knob down for Mirror folding & again for
mirror unfolding.
PINOUT DETAILS
