SUPPLEMENTARY RESTRAINT SYSTEM (SRS)
9
Sr.
No.
DESCRIPTION
FASTENER
TIGHTENIG
TORQUE (Nm)
LOCATION
4
PAB unit
mounting on
bracket
Hex Flange
screw M6X16
8 ± 1 Nm
5
PAB unit
mounting on side
bracket
FLANGE
BOLT M5
8 ± 0.4 Nm
6
Front Seat Belt
Bottom
7/16" 20UNF-
2A * 56 mm
(PLAIN)
45 ± 5 Nm
7
Front Seat Belt
WITH Height
adjuster Top
7/16" 20unf
Torx Head
25.4 mm
BOLT
54 ± 5 Nm
