49 / 418
1.2L REVOTRON ENGINE
38
Special Installation :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TOQUE
(Kgf.m)
1 Belt
2 Hex FL Bolt M8X30 for Tensioner (Qty 2)
3.5
3 Belt Tensioner
4 Bracket for Compressor Mounting
5 Hex FL Bolt M8X28 (Bracket to block) (Qty 4)
3.5
6 Compressor
7 H/FL Bolt M8X85 for Compressor (Qty 3)
2.2+0.2
8 Hex. FL Bolt M8X100 for Water Pump (Qty 4)
2.5
9 H/FL Bolt M8X55 for water pump
10 Water Pump
11 Hex FL Nut AM6 to Thermostat
1.0
12 Bracket lambda sensor
13 Thermostat
14 Alternator
15 Alternator Cover Fitment Bracket:
16 Alternator Guard
17 Hex FL Nut AM6 for Guard (Qty 2)
1.0
18 Hex. FL Bolt M8X85 for alternator (Qty 3)
3.5
19 Water Temperature Sensor
1.8-2.5
