901 / 924
SUPPLEMENTARY RESTRAINT SYSTEM (SRS)
22
6. Loosen and remove both mounting bolt and
take out the RPLL assembly along with belt.
FITMENT
Follow reverse procedure for fitment.
SECOND ROW SEAT BELT ELR
REMOVAL
1. Disconnect the battery connection.
2. Fold the second row seat.
3. Remove lower “C” pillar trim. (For procedure,
refer Body section.)
4. Remove bottom anchorage bolt of the seat
belt.
5. Remove upper “C” pillar trim. (For procedure,
refer Body section.)
6. Remove two mounting bolts and take out the
ELR assembly
FITMENT
Follow reverse procedure for fitment.
