BODY
15
10. Remove mounting nut of steering column pull
out cap.
11. Remove screw at glow box location and pay
out glow box.
12. Remove mounting screw and pull out the
center lower panel.
13. Remove mounting screw of control module.
14. Remove combination switch assembly and
ignition switch assembly (For procedure refers
combination switch and ignition switch
removal process in Electrical section.)
15. Pull Out the bezel cover and disconnect the
peps start stop switch.
16. Pull out the instrument cluster hood.
