TRANSAXLE - TA65 Star
20
12. REMOVAL OF TRANSAXLE FROM
VEHICLE
:
1. Shift the fuse box at battery tray position (Refer
fuse box shifting procedure).
2. Lift the vehicle on using two post lift and
remove the front wheels.
3. Drain the Transaxle oil.
4. Disconnect Electrical connection to the Neutral
position sensor.
5. Disconnect gear shifter and selector cables.
6. Disconnect clutch release cable from clutch
release lever.
7. Remove Drive shaft Lock Nut.(Note: Apply
Brake while removing Lock nut.
8. Remove Brake Caliper mounting and hang it
on vehicle using S-hook.
