BODY
54
9.2.34 ROOF LINEAR
REMOVAL
1. Remove primary door seal of the front and rear
door from panels.
2. Remove A pillar upper trim.
(For removal refer
A pillar removal process).
3. Remove B pillar upper trim.
(For removal refer
B pillar removal process).
4. Remove C pillar upper trim.
(For removal refer
C pillar removal process).
5. Remove the two sunvisors.
(For removal refer
Sunvisor removal process).
6. Remove the roof lamp.
(For removal refer
Electrical section).
7. Remove the three grab handle.
(For removal
refer grab handle removal process).
8. Remove microphone, if fitted
. (For removal
refer Electrical section).
9. Remove Roof liner inner cover by pulling it
downwards.
10.Remove three screws from roof liner plastic
bracket.
11.Remove the antenna’s electrical connection.
(For removal refer Electrical section).
12.Fixing provided in between two sun visors on
the inner of the roof liner. Pull out accordingly.
13.Remove the roof trim.
FITMENT
For fitment follow reverse procedure of removal.
