BODY

42

9.2.22 INNER REAR VIEW MIRROR

REMOVAL

1. Push the mirror in the upward direction along

with the windshield to remove the same.

FITMENT

For fitment follow reverse procedure of removal.

9.2.23 FRONT ROW SEAT

REMOVAL

1. Slide the Front seat at front and remove the

three rear mounting screw.

2. Slide the Front seat backwards and remove

the two front mounting screw.

3. Push Front Seat at Front.

4. Remove the front Seat.
