BODY
24
9.2.8 REAR BUMPER
REMOVAL
1. Open the rear trunk.
2. Loosen and remove four rear bumper special
screw on top side.
3. Loosen and remove all rear bumper screws
and bolts which hold the rear bumper from
bottom side.
4. Loosen and remove two screws which are
inside the wheel arch. Follow the same
procedure at the other end.
5. Pry out the bumper edges from the wheel arch.
6. Take care that the hood seal is removed for
easy removal of bumper.
7. Remove all the electrical equipments mounted
on the rear bumper.
FITMENT
For fitment follow the reverse procedure of
removal.
