ELECTRICAL
214
28.14. REAR VIEW CAMERA
The rear-view camera is usually wired to automatically sense the transmission is set in reverse, and it shows
the rear view while the car is in reverse .Camera module with compact housing to be mounted on the rear
rub rail by using a holder and bracket, in order to transmit a video signal of the desired area to an external
display.
The display in the TFT is configured to switch on automatically, as soon as a video signal has been received.
The camera covers a very broad visual range: Up to 92 degrees vertical and 124 degrees horizontal. Hence
it is possible to see the road directly behind the vehicle. Simultaneously both outer edges of the bumper can
be seen. The rear view camera has considerable night-view capabilities, so that even standard reversing
lamps provide sufficient light to convey a clear image of the area behind the vehicle on the TFTdisplay
LOCATION:
It is located on Tailgate garnish.
