STEERING
9
5. Remove steering wheel using steering wheel
puller. (Part No. 8855TOOL0001)
CAUTION
Don't excessive force or hammering on steering
wheel for fitment;
CAUTION
Care should be taken such that self-cancellation
lugs do not get damaged (self-cancellation lugs are
shown in below figure with arrows).
INSPECTION:
Check for any damage to self cancellation lugs, if
found, replace complete steering wheel
INSTALLATION:
1. Align the marks made on the steering wheel
and the shaft. Install steering wheel on steering
shaft
2. Tighten the steering wheel nut to the
specified torque.
Tightening torque (Steering wheel nut) = 4Kg-m
3. Fit horn pad (Press fit type).
4. Connect battery.
