ELECTRICAL
266
FUSE AND RELAY REPLACEMENT
Removal
Fuse box is located behind the glove box. To
access the fuse box, Glove box needs to be
removed first.
Remove
1. Remove snap fitted end-cover first.
2. Remove mounting screws at glow box
location
3. Remove screw at bottom and upper side
glow box and pay out glow box.
4. Disconnect the electrical connection of switch,
glove box lamp.
5. Disconnect the electrical connection of glove
box lamp.
6. Take out the glow box.
7. Pull out the fuse from fuse box modules from
available cutout as shown below
