609 / 948
BODY
51
2.31
REAR QUARTER TRIM
REMOVAL
1. Remove parcel shelf.
2. Remove Tailgate Side inner Beading.
3. Remove Rear Door Beadings at rear quarter
location.
4. Remove rear seat (for removal process refer
rear seat removal process).
5. Remove rear seat belt (for removal process
refer seat belt removal process)
6. Pull out the cap of rear quarter trim
7. Remove the mounting screw rear quarter trim
8. Remove the mounting screw rear quarter trim
9. Pull out the clip and pull out trim
FITMENT
For fitment follow reverse procedure of removal.
