3. CONSTRUCTIONAL AND SERVICE DETAILS
ENGINE MOUNTS
DESCRIPTION
(TIGHTENING
TORQUE
(N-m))
NO REUSE
Left Mount Bolt
120
Left Mount to Frame Rail Bolts
90 + 45°
Left Mount Bracket Bolts
40 + 45°
Right Mount to Frame Rail Bolts
60 + 45°
Right Mount Bolt
90 + 45°
Rear Mount to Bracket Bolt
90 + 45°
Rear Mount Bracket to Transmission Bolts
90 + 45°
Rear Mount to Crossmember Bolt
90 + 45°
CYLINDER HEAD
DESCRIPTION
TIGHTENING
TORQUE
(N-m)
NO REUSE
Upper Head Engine
25
Cylinder Head Bolts
65 + 90° + 90° +
90°
Glow Plugs
8
Upper Engine Cylinder Head Caps
14
ENGINE COVERS
DESCRIPTION
TIGHTENING
TORQUE (N-m)
NO REUSE
Engine Oil Drain Plug
20
Crankcase Bolts
9
Crankcase Bolts
25
Front Cover Oil Seal Bolts
9
Front Cover Oil Seal Bolts
9
Rear Oil Seal Bolts
9
CRANKSHAFT AND FLYWHEEL
DESCRIPTION
TIGHTENING TORQUE
(N-m)
NO REUSE
Flywheel Bolts
160
Crankshaft Bearing Caps Bolts
25 + 100°
