CLUTCH RELEASE SYSTEM
10
8. Mount clevis pin on booster assembly from
brake pedal.
9. Fix Split pin to connect brake pedal to brake
booster assembly.
10. Connect Electrical connection to contactless
clutch sensor.
11. Fix Spring clamp connection to TMC (Tandem
master Cylinder).
12. Fix the connection on CMC.
13. Assemble dashboard lower from driver side.
