ELECTRICAL
66
15. FASCIA SWITCHES
PDC, fog lamps are located on fascia switches
DESCRIPTION
1 REAR FOG
2 FRONT FOG
3 HAZARD
4 ECO
5 SPORT
FASCIASWITCH PANEL
REMOVAL
1. Carefully pry out dashboard_center_armature.
2. Loosen and remove the mouting screw of
infofitment and carefully pry out.
3. Disconnect all the electrical connection from
the fascia switch assembly.
