ELECTRICAL
51
10 POWER SOCKETS
One power sockets of 12V DC-10 amps each are
provided as shown in these can be used for
connecting loads up to 10A maximum. To use this
socket, open the cap first.
1. Front power socket
REMOVAL AND REFITMENT
1. Remove the arm rest.
(For procedure refer Arm
rest removal process in Body section.)
2. Disconnect one electrical connections behind
the floor console assembly. Pry out Socket
holder assembly from bezel.
(For procedure
refer console removal process in Body
section.)
REFITMENT
Install the power socket in the reverse order of
removal.
