ELECTRICAL
36
4. Remove Rear fog lamp locking clip.
REFITMENT
For refitment follow the procedure in reverse.
7.11 FRONT FOG LAMP
The fog lamps are located in the lower part of the
front bumper. The bulb used for the fog lamp
function is a halogen H16 bulb, 12V - 19W.
Fog lamp on/off is done by using master light
switch.
REMOVAL:
1. Open engine hood & ensure all lamps are in
OFF condition.
2. Remove the front bumper (For procedure refer
Front bumper removal process in Body
section.)
3. Loosen and remove the fog lamp mounting
fasteners and full out it.
