C635 TRANSAXLE
39
15.Remove the gear shifter cable from the bracket
by pulling back on the locking collar and lifting
the cable out of the bracket.
14.ASSEMBLY GEARSHIFT CONTROL CABLE
Follow the Reverse Procedure of Disassembly
Gear Control cable
15.REMOVAL GEARSHIFT MECHANISM
1. Remove screw & pull out side shield from LH &
RH side.
2. Remove Handle from LH & RH side.
3. Remove 1 screw & 6 clips Console Finisher side
garnish from LH & RH side.
