BODY

59

4. Remove four Push on Nuts.

5. Remove front wheel arch liner.

FITMENT

For fitment follow reverse procedure of removal.

2.42 REAR WHEEL ARCH LINER



REAR WHEEL ARCH FRONT

REMOVAL

1. Remove clip push button of front cladding,

fender.

2. Pull out the cladding fender.

3. Remove mounting Clip Rear wheel arch liner

front.
