C635 TRANSAXLE
51
13.Install first gear and the bearing using and a
suitable press.
14.Install a
NEW
rear bearing retention bolt, tighten
to 110 Nm (81 ft. lbs.).
22.DISASSEMBLY OF OUTPUT SHAFT2 (3
RD
,
4th and REV.)
1. Remove the
LEFT HAND
thread rear bearing
retention bolt and
DISCARD
.
2. Remove the rear bearing and reverse gear from
the shaft using, and a suitable press.
Drift Part No.2779 5890 3504
Press mounting plate 5412 5890 2606
