ELECTRICAL
103
REMOVAL& INSTALLATION
REMOVAL
1. Remove the door trims
(Refer Body Section for
removal procedure)
.
2. Gently pry out the switch bezel fromthefront door
by pushing the mounting clip with the
screwdriver.
3. Remove the switch assembly from bezel.
4. Disconnect the electrical connector & take out
the switch assy.
Same procedures are to be followed for co-drivers
and passengers window module switches
INSTALLATION
1. Connect the electrical connector of switch.
2. Position the switch onto the bezel and push fit
the assembly.
NOTE
Follow the same procedure to remove remaining door
window winding switches.
