ELECTRICAL
35
13.Pull the Lamp Outside (-X Axis) Disengaging
From Catcher.
REFITMENT
Follow the removal procedure in reverse.
7.10 REAR FOG LAMP (HIGH VERSION ONLY)
LOCATION
The Rear fog lamp is located in the lower part of
the Rear bumper.
REMOVAL
1. Ensure all lamps in OFF condition.
2. Remove Rear bumper
( for removal procedure
refer body section )
3. Disconnect Rear fog lamp Connector.
