24. Loosen remove the screw and pay out the
instrument panel, lower
25. Remove mounting bolts of dashboard
26. Disconnect two connections behind the
control panel assembly.
27. Remove A pillar Lower trim. (For procedure
refer A pillar trim removal process.)
28. Remove two mounting screw near A
pillar.(LH,RH)
29. Disengage 3 locators located on BIW plenum
panel brackets.
30.Remove the dashboard, while removing
Dashboard carefully disengage HVAC system
behind the glove box.
FITMENT
For fitment follow reverse procedure of the
removal.
