29 / 948
KRYOTEC ENGINE
20
PISTONS AND CONNECTING RODS
DESCRIPTION
TIGHTENING
TORQUE (N-m)
NO REUSE
Connecting Rod Cap Bolts
25 + 60°
TIMING CONTROL
DESCRIPTION
TIGHTENING
TORQUE (N-m)
NO REUSE
Mobile Tensioner
25
Fixed tensioner Bolts
50
Crankshaft Bolts
340
Camshaft Pulley Bolt
30 + 40°
Protection cover of timing control
9
Tensioners Support of Timing Belt Bolt
25
Timing big bracket
50
ENGINE TURBOCHARGER SYSTEM
DESCRIPTION
TIGHTENING
TORQUE (N-m)
NO REUSE
Turbocharger Nuts
25
Engine Oil Pressure Pipe to the Turbocharger
26
Engine oil pressure pipe to the turbocharged
25
Duct engine oil return from the turbocharger - base side Bolt
50
Oil return tube turbocharger engine turbocharger side Bolt
9
INTAKE AND EXHAUST MANIFOLDS
DESCRIPTION
TIGHTENING
TORQUE (N-m)
NO REUSE
Intake Manifold Nuts
25
Exhaust Manifold Nuts
20
LUBRICATION SYSTEM
DESCRIPTION
TIGHTENING
TORQUE (N-m)
NO REUSE
Engine Oil Filter Cover
25
Output Pipe From Turbocharger Engine Oil Bolt
50
Oil Pressure Pipe to Turbocharger Bolt
15
Turbocharger to Cylinder Head Oil Pressure Pipe Bolt
25
Oil Pressure Warning Light Switch
25
Oil Pressure Switch
20
Introducing Engine Oil Nozzle
9
Displacement Control Valve Oil Pump motor
7
