C635 TRANSAXLE
41
10.Disengage the gear engagement cable end
from the lever by rotating the cable to one side
and prying it off in the direction that continues
the rotating motion.
11.Remove all 4 screws on Shifter mechanism
Unit.
12.Take out shifting Mechanism unit from vehicle.
16.ASSEMBLY GEARSHIFT MECHANISM
Follow the reverse procedure of Gearshift
mechanism Removal.
17.ASSEMBLY DIFFERENTIAL OIL SEAL
1. Fix differential oil seal using Tool no
2654 5890
3511
DRIFT 2654 5890 3511
NOTE:
1. USE TOOL NO.
2654 5890 3511
FOR ON
VEHICLE OIL SEAL ASSEMBLY OPRATION.
USE STANDARD TOOL FOR REMOVAL OF OIL
SEAL ASSEMBLY OPERATION.
