STEERING
13
3. Turn off the IGN switch and wait for 20 sec or
more. Then do regular check after starting
the engine.
Tightening torque value is 18-22 Nm.
Erase the DTC if available.
NOTE:
Do not open the servo unit for any repair
because it is precisely calibrated.
2.3.5 MOTOR REMOVAL
1. Disconnect battery. (Refer battery removal
procedure/Body Electrical group).
2. Remove steering wheel (
Refer Steering wheel
removal procedure).
3. Remove two screws and one nut of cover
nacelle.
4. Remove lower panel covers attached to the
dashboard.
5. Disconnect
the
multifunction
switch
connector.
6. Remove the column outside.
7. Remove the mounting bolt and remove
motor..
REFITMENT:
1. Conduct the
“Calibration” and “ECU” variant
(Petrol or Diesel “ by TATA tool.
2. Erase the DTC if available.
3. Turn off the IGN switch and wait for 20 sec or
more. Then do regular check after starting
the engine.
Tightening torque value is 18-22 Nm.
