7. Remove instrument cluster.
(For procedure
refer instrument cluster removal process in
Electrical section).
8. Pry out gap hider fitted on the dashboard sub
assembly.
9. Pry out center facia and air vent assembly
along with Hazard switch and Fascia switch.
10.Disconnect the electrical connection of Hazard
switch.
11.Disconnect the electrical connection of fascia
switch.
12.Remove music system
(If applicable). (For
procedure refer music system removal process
in Electrical section).
13.Remove floor console assembly.
(For
procedure refer floor console removal
process).
14.Remove PAB Assembly
(If applicable). (For
procedure refer PAB removal process in SRS
section).
15.Remove A-pillar upper trim on LH and RH
side.
(For procedure refer A pillar trim removal
process).
