HVAC
42
C. CONTROL PANEL REMOVAL AND ASSEM-
BLY
1. Pull out end cover.
2. Remove one mounting screw on co-driver side
armature.
3. Remove the co-driver side armature.
4. Remove Climate control bezel.
5. Remove four mounting screws on control panel.
6. Remove Electrical Connection on control Panel &
take out control panel.
FITMENT
For fitment follow the reverse procedure of removal.
