BRAKES
50
REMOVAL AND REFITMENT OF TANDEM
MASTER CYLINDER
(TMC)
& BOOSTER
ASSEMBLY
REMOVAL
1. Position vehicle on two post lift and
disconnect battery.
2. Drain the brake fluid from the brake circuit.
(For procedure refer brake fluid draining in this
section.)
3. Disconnect the electrical connector of brake
fluid level switch.
4. Disconnect vacuum hose from brake booster.
5. Remove the spring band clamp at the CMC
end and hold the CMC to reservoir connecting
hose in vertically upward position to avoid any
further loss of fluid and plug the openings with
suitable cap.
6. Loosen coupling nuts and disconnect
hydraulic lines attached to TMC.
7. Loosen and remove the mounting nuts and
remove the TMC assembly from the vehicle.
FITMENT
For fitment follow reverse procedure of removal.
TMC mounting nuts tightening torque 1.8±0.3 Kgf-
m.
