C635 TRANSAXLE
23
8. FLUID
FLUID DRAIN AND FILL
The transmission does not require scheduled
maintenance and should be performed only as a
result of revision operations for control /
replacement of internal components. Therefore in
all other operations of removal and installation,
gearbox oil is to be reused.
CAUTION:
Possible foreign bodies in the container or in the
storage area can compromise the reutilization of
the manual gearbox oil.
The transmission oil collection and its storage
before re-use should be made with a clean
container with a protective cover.
1. Raise and support the vehicle.
2. Remove the transmission fill plug and check
that the oil level is just below the bottom edge of
the fill hole.
3. If oil level is low, add the recommended oil
(Vehicle Recommended Fluids/Specifications).
4. Remove transmission drain plug to allow the oil
to into a suitable drain pan.
NOTE:
Do not spill any oil because the indiscriminate
dispersal of the product contributes to pollution.
5. Clean, then install the drain plug and tighten to
the proper (Torque Specifications).
6. Check that the oil level is just below the bottom
edge of the fill hole.
7. Clean the filler cap and install it in the
transmission.
FLUID LEVEL INSPECTION
Remove the transmission fill plug and check
that the oil level is just below the bottom edge
of the fill hole.
If oil level is low, add the recommended oil
(Vehicle Recommended Fluids/Specifications).
Clean the filler cap and install it in the
transmission.
