13 / 71
540 G/R 0.75 (PA)
FRT
709 V/GY 0.75 (ALL)
FRT
57D R/Y 0.75 (ALL)
FRT
780 L/G 2.50 (ALL)
FRT
709 V/GY 0.75 (ALL)
FRT
35D G/R 2.50 (ALL)
FRT
31A G/O 0.50 (ALL)
CAB
338C Y/R 1.00 (ALL)
FRT
52 G/R 0.75 (PS)
FRT
363 G/R 0.75 (PA)
CAB
275 R/Y 2.50 (ALL)
CAB
275 R/Y 2.50 (ALL)
FRT
551A V/Y 0.75 (ALL)
FRT
7 BR 0.50 (ALL)
FRT
350 GY/V 0.75 (ALL)
FRT
70 G/R 0.75 (PA)
FRT
72 G/R 0.75 (PA)
CAB
407 G/R 0.75 (PA)
CAB
376 R/Y 2.50 (K)
FRT
373B Y/O 0.50 (NK)
FRT
166 Y/B 4.00 (ALL)
FRT
546 G/O 0.50 (ALL)
FRT
34 Y/B 4.00 (ALL)
CAB
Compressor
EF3
10.0 Amps
Starter Motor Sol
EF19
30.0 Amps
-
EF
15.0 Amps
Blower Motor
EF20
40.0 Amps
C001YM C001YF 3
C001YM C001YF 4
NR
C
B
A
14PP028135
14PP028120
14PP028093
14PP028073
08.10.18
24.08.18
12.06.18
11.06.18
S57
COMPRESSOR FUSE
SHEET 24 EMS
SHEET 24 EMS
WB057
Sheet8
WB365
Sheet9
HORN RELAY
SHEET 45 EXTERIOR LIGHTING
WB225
Sheet10
AC CLUTCH
WB356
Sheet10
WB365
Sheet9
UNDERBONNET FUSE BOX
Fuel Pump
R17
20.0 Amps
C001UM C001UF 2
Q501/Q502
UNDERBONNET F/B
SOP RELEASE
PP RELEASE
PO RELEASE
BETA II RELEASE
PR SK TS
PR IW TS
PR IW TS
DR4
PHASE
DESIGN
PR IW TS
TS 30.09
PSOA
NTS
1
HM 30.09
RP 30.09
C001UM C001UF 13
C001UF C001UM 45
AC Clutch
R18
20.0 Amps
5412 5400 0007
A3
12
70
SHEET 30 FUEL PUMP
SHEET 18 EARTH
SHEET 31 HVAC MANUAL
SHEET 24 EMS ECU
C001BEM C001BEF 1
Brake Lamp
EF9
5.0 Amps
Horn High/Low Tone
EF5
15.0 Amps
C001UF C001UM 44
ABS ECU
EF6
25.0 Amps
WB105
Sheet6
BATT SUPPLY
EMS BATT BS IV
EF2
5.0 Amps
SHEET 33 ABS/ESP
EMS ECU
BLOWER RELAY
WB341
Sheet8
WB328
Sheet12
FUEL PUMP
EF10
20.0 Amps
C117A-5W
C117A-1W
C117A-5X
C117A-1X
C117A-3W
C117A-4W
C117A-4X
C117A-3X
C117A-F10
C117A-F9
C117A-F5
C117A-F6
C117A-X
C117A-F3
C117A-F19
C117A-F2
C117A-F20
