KRYOTEC ENGINE
87
2. Remove DPF to EGR lines.
NOTE
Do not reuse the line once removed; use new line
at the time of assembly.
3. Remove mounting fasteners and take out DPF
heat shield.
4. Remove top clamp and two bottom bolts and
take out DPF assembly.
5. Remove two mounting bolts and take out DPF
support bracket.
6. Remove mounting fasteners and take out
dipstick tube.
7. Loosen mounting clips and disconnect coolant
supply hose to oil cooler.
