ELECTRICAL
92
REMOVAL
1. Remove Infotainment System
(Refer Electrical
Section for removal procedure)
.
2. Remove the mounting fasteners and take out
the unit.
3. Disconnect all the electrical connection to the
silver box and take it out.
REFITMENT
For refitment follow the removal procedure in
reverse.
17.6 TWEETERS
Tweeter is a loudspeaker designed to produce high
frequencies.
1. LOCATION
There are total four tweeters. Each is fitted inside the
A pillar and rear door.
