BRAKES
51
NOTE
Make sure that lines are fitted correctly i.e.
primary outlet is connected to front brakes and
secondary outlet is connected to rear brakes.
Connect clutch hose.
After refitment bleed the brake circuit.
Do not overhaul the TMC assembly as it is
not serviceable and needs to be replaced
as an assembly.
BOOSTER NRV
REMOVAL
1. Disconnect the spring band clamp and remove
the vacuum line connected to the non-return
valve.
2. Loosen and remove the NRV from the booster
by rotating it in anticlockwise direction.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Vacuum pipeline routine/ vacuum hose orientation
to be ensured after fitment.
