KRYOTEC ENGINE
115
16. Position the index of the tensioner at the
maximum reference by pressing in upward
direction. In this position tighten the tensioner
bolt.
17. Rotate the crankshaft two complete
revolutions. Loosen the timing tensioner bolt.
18. Use a screwdriver to position the index of the
tensioner at the reference hole.
19. In this position tighten the tensioner bolt to the
proper torque.
20. Align engine mounting bracket and adjust the
spacer if necessary.
21. Install engine mounting bracket at timing side.
22. Install the bottom timing belt cover.
23. Install damper pulley.
