DRIVETRAIN-TA65 Star
66
5.7. Q: REMOVAL OF GEAR SHIFTER
HOUSING, GEAR SHIFTER AND
SELECTOR CABLE:
1. Ensure the gear lever in neutral condition.
2. Remove the central floor console after
removing the lever knob, washer, cap screw
and base plate
NOTE:
For removal of central console refer BODY
group of BOLT.
3. Remove the lock pin and pry out the shifter
cable as shown figures.
4. Loosen/remove selector cable fastener to
remove selector cable.
5. Pry out both the cable lock plates and remove
the cables from assembly gear shift housing.
6. Unscrew the four bolts of gear shifter lever
housing to remove it.
