DRIVETRAIN-TA65 Star
45
NOTE:
1. Apply anabond 112 on threads of all fasteners
2. Apply RTV silicon liquid gasket anabond 676
on housing interface.
3. The chips collected by magnetic drain plug,
are to be removed at the time of every oil
change.
4. Keep inner and outer races of taper roller
bearing in sets.
5. Use sealing anaerobic compound for all oil
seals outer diameter.
6. For oil seals of input drive shaft and bellows
use anabond 112.
5.7. G. INPUT SHAFT SUB ASSEMBLY:
1.Remove deep groove ball bearing (rear) by
using holder part no. 2702 5890 2606 with
puller part no. 2654 5890 3508.
2. Remove deep groove ball bearing (front) by
using puller part no. 2657 5890 2801 (Fig.34).
