DRIVETRAIN-TA65 Star
43
22. Remove lock plate input shaft bearing from
housing (rear half) by unscrewing the screws.
23. Remove the hex flanged bolts on the housing
Remove reverse switch & speedo sensor.
24. Rotate the transaxle upside down. Remove
the hex flange bolts provided at clutch
housing.
25. Remove the gear box housing (rear half) by
gently tapping with a mallet.
26. Remove reverse idler shaft, reverse idler
gear. Reverse lower bracket Assy.
