ELECTRICAL

64

12.16 STEERING LOCK CUM IGNITION

SWITCH

FUNCTION

To lock the steering wheel

To start & stop the engine

To switch on accessories and other electrical

system

LOCATION

Fitted on steering column.

REMOVAL & REFITMENT OF STEERING

LOCK CUM IGNITION SWITCH (SLCIS):

REMOVAL:

1. Disconnect battery negative terminal.

2. Remove steering nacelle. Refer “Removal &

refitment of steering nacelle" from steering

section.

3. Remove steering wheel. Refer “Removal &

refitment of steering wheel" from steering

section.

4. Remove combi switch. Refer “Removal & refitment

of combi switch."

5. Disconnect steering lock cum Ignition

switch connection.

6. Unscrew Steering Lock Cum Ignition Switch

mounting screws.
