1.4.23. FRONT ROW SEAT
REMOVAL
1. Slide the Front seat backwards and remove
the two front mounting screw.
2. Slide the Front seat at front and remove the
three rear mounting screw.
3. Push Front Seat at Front.
4. Remove front Seat.
FITMENT
1. Locate the front seat assembly in BIW using
Locating Pin.
2. Fix the seat assembly at front by tightening two
mounting screws.
3. Slide the front seat forward most position.
4. Fix the seat assembly at rear by tightening
three mounting screws.
