Water Pump, Thermostat and Components
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TOQUE
(Kgf.m)
1 Water Pump Assy.
2 Seal (Water Bypass Tube)
3 Pipe Union Bolt 10 M14x1.5
2.5
4 Sealing Washer 14x18 (2 Qty)
5 Adapter (Water Bypass)
3.5
6 Clamp (Oil Cooler Inlet Hose)
7 Tube Assy. Oil Cooler Coolant Inlet
8 Tube Assy, TC Coolant Intake
9 Sealing Washer 12x15.5 (4 Qty)
10 Pipe Union Bolt 8 M12x1.5 (2 Qty)
2.5
11 Tube Assy, TC Coolant Return
12 Sealing Washer 12x15.5 (4 Qty)
13 Pipe Union Bolt 8 M12x1.5 (2 Qty)
2.5
14 Adapter (Water Bypass)
3.5
15 Housing, Thermostat
16 Thermostat Assy.
17 Thermostat
18 Insert (3 Qty)
19 Hex Flange Screw M6x18 (3 Qty)
1.0
20 Adapter (Cyl. Head Vent)
1.0
21 Sealing Washer 14x18
22 Hex Flange Nut AM6 (3 Qty)
1.0
23 Stud CM6x20 (3 Qty)
24 Pipe Union Bolt 10 M14x1.5 (2 Qty)
2.5
25 Sealing Washer 14x18 (4 Qty)
