STEERING
11
1.2.3.3. INTERMEADIATE SHAFT REMOVAL
1. Loosen the universal joint bolt between
steering column & intermediate shaft.
2. Remove the universal joint bolt between
intermediate shaft and rack & pinion assembly.
3. Disengage the intermediate shaft from rack &
pinion assembly and take out the intermediate
shaft.
REFITMENT:
For assembly follow reverse procedure of
removal.
NOTE:
Do not reuse the universal joint bolts.
1.2.3.4. RACK & PINION ASSEMBLY REMOVAL
1. Remove lower universal joint bolt and make
steering rack free from the steering column
assembly.
2. Remove both front wheels (Refer wheel
removal procedure / Wheels and tyres group).
3. Remove tie rod ball joint nyloc nut.
4. Remove tie rod end by using tie rod ball joint
puller. (Part No. 2871 5890 4601).
