1.5L REVOTORQ ENGINE
29
Timing Belt, Timing Cover, Auto Tensioner, Water pump
ITEM
NO.
DESCRIPTION
NO REUSE SEALANT
LUBRICATIONTIGHTENING
TORQUE
(kg-m)
01 Hex. Flange Bolt M6x20 (Qty. 3) 0.8
02 Timing Cover Assy., (Front)
03 Hex. Flange Bolt M6x25 (Qty. 4) 0.8
04 Hex. Flange Screw M6x25 0.8
05 Hex. Flange Bolt M6x45 (Qty. 2) 0.8
06 Hex. Flange Screw M6x16 (Qty. 2) 0.8
07 Hollow Dowel (Qty. 2)
08 Front Cover (Bottom)
09 Gear, Crankshaft
10 Timing Belt
11 Hex_Screw_M6x20 (Qty. 5) 1.0 + 0.2
12 Hollow Dowel (Qty. 2)
13 Water Pump Assy.
14 Gasket (Water Pump)
15 Hex. Flange Bolt M12x69 4.5
16 Idler Pulley
17 Spacer (Timing Belt Idler)
18 Cap Screw M6x16 0.8
19 Hex. Flange Screw M6x16 (Qty. 3) 0.8
20 Pin (Timing Cover Mounting)
21 Timing Cover Assy., (Back)
22 Timing Gear - Camshaft ( Front )
23 Washer For Camshaft Gear
24 Hex. Bolt (Camshaft Gear Mtg.) 11.5 + 0.5
25 Auto Tensioner Assy.
