1.2L REVOTRON ENGINE
143
VII. Removal of Cylinder Head And Camshaft
1. Remove the rear intermediate bearing of the
camshafts.
2. Remove the Camshaft Bearing Caps
attaching bolts, starting from the ends of the
cylinder head and working inwards to center.
3. Remove front ITG bearing cap upper.
4. Remove both the camshafts.
CAUTION
When removing the camshaft, use care to
avoid damaging the bearing surfaces of the
cylinder head and the camshaft.
