ELECTRICAL
126
TELL TALES
COLOR
INDICATOR
REMARKS
Seat belt
warning
Red
Seat belt warning indicator comes ‘ON’ for 4 seconds, when
ignition is turned ‘ON’.
If seat belt is not fastened and lamp shall be made ON
continuously for 30 sec.
If seat belt is not buckled and vehicle speed goes above 4
kmph, Telltale shall be ON as initial warning with No audio
chime. Telltale shall turn OFF when vehicle speed goes
below 2 kmph.
If seat belt remains unbuckled and vehicle speed goes
above 15 kmph, Final Waring shall start. Audio Chime shall
continue for 30 seconds. Seat belt telltale shall remain
continuously ON when audio alarm is active.
Seat belt audio alarm shall not turn ON if reverse gear is
engaged.
Airbag status
Red
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF.
It will continuously illuminate when there is malfunction of
airbag (SRS) system. Contact TATA MOTORS Authorized
Service Centre urgently.
EPAS
Amber
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF.
Illuminates when there is a fault in the EPAS. Contact
TATAMOTORS Authorized Service Centre urgently.
Low Coolant
Temperature
Blue
Indicates that engine coolant temperature is very low.
Illuminates
when engine coolant temperature is very low
and continuously
flashes along with buzzer if engine coolant
temperature is extremely low. Contact TATA MOTORS
Authorized Service Centre urgently.
High Coolant
Temperature
Red
Indicates that engine coolant temperature is very high.
Illuminates when engine coolant temperature is very high
and continuously flashes along with buzzer if engine coolant
temp. is extremely high. Switch off the engine and allow
cooling. Top-up coolant if coolant level is low. Contact TATA
MOTORS Authorized Service Centre urgently.
Low Fuel
Amber
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF. Illuminates continuously if
fuel level is less than a pre-defined minimum level. Refill the
fuel tank as soon as possible. IMPORTANT: The warning
light flashes to indicate a fault in fuel system. Contact TATA
MOTORS Authorized Service Centre urgently.
NOTE: Driving with low fuel level condition can cause the
engine to misfire and damage the catalytic converter (if
equipped).
