1.2L REVOTRON ENGINE
64
15. Stop the engine and allow to cool
sufficiently.
16. Add pre-mixed 40:60 coolant to the reservoir
until the coolant level is at the 'MAX' mark on
the bottle.
III. AIR FILTER ELEMENT REPLACEMENT
DESCRIPTION
Proper maintenance of the air filter is essential
for vehicle performance and fuel economy.
The air filter element removes foreign material
such as dust, dirt, and other material from the
intake air, thereby preventing the engine from
damage due to contaminated air.
Inspect and clean the air filter element at every
routine service. Replace the air filter element
every 45,000 km.
REMOVAL
1. Park the vehicle on a level surface, engage
the parking brake, and raise the hood.
2. Gently tap loose any dirt or debris from the
filter. Clean the housing and air ducts as
well. Take care not to allow dirt and debris
to enter the air inlet to the engine.
3. Remove the clamp and take out the air filter
outlet hose.
4. Unscrew the top cover mounting bolts of air
filter assembly.
