1010 / 1265
ELECTRICAL
106
REMOVAL& INSTALLATION
REMOVAL
1. Gently pry out the switch bezel from the front
door by pushing the mounting clip with the
screw driver.
2. Remove the switch assembly from bezel.
3. Disconnect the electrical connector & take out
the switch assy.
Same procedures are to be followed for co-drivers
and passengers window module switches
INSTALLATION
1. Connect the electrical connector of switch.
2. Position the switch onto the bezel and push fit
the assembly.
NOTE
Follow the same procedure to remove remaining
door window winding switches.
